Available in the following colours





PiloTCar PC-H Features

Power

Motor Power

4 kW (5.44 hp) Rated
— 9.60 kW (13 hp) Peak

6 kW (8.20 hp) Rated
— 12.46 kW (16.95 hp) PeakBattery

Battery

6X8V TROJAN T-875: (8.16 kWh)
Lithium Battery Package

Charge Unit

Lead-Acid Battery Package: DELTA-Q QuiQ 1000 Onboard
Charge Unit: 110-220 VAC@8 1A/48V
Lithium Battery Package: OVARTECH 3.3 kW Onboard
Charge Unit: 85-265 VAC@16A 40A/48VMotor Control Unit

Motor Control Unit

AC: CURTIS (350 A-450 A)

Steering and Suspension System

Steering

  • Self-compensating double reduction helical rack-and-pinion

Suspension Front

  • Fully independent McPherson style strut suspension

Suspension Rear

  • Semi independent, swing arm with coil springs over hydraulic shock absorbers

Brake System

Service Brake

  • Self adjusting mechanical, rear wheel drum brakes and regenerative brake
    Option: 4-wheel hydraulic drum brake system

Parking BRake

  • Foot actuated multi-lock parking brake
    Option: Elektromagnetic parking brake

Body

Body

  • Naturally colored Thermoplastic ABS
    White, Midnight Blue, Red, Black

Chassis

  • Automotive style steel frame with high corrosion resistance
    Sanding /E-coating/ Static Wet Paint

Performance

Speed

Forward: 15 mph - 25 mph (24 kph - 40 kph)*

Reverse 5 mph (8 kph)

Range

Lead-Acid Battery Package
37 mi (60 km) **

Lithium Battery Package
55.5 mi (90 km) **

Max Gradeability: 25%

Charge Time

Lead-Acid Battery Package
80% - 6 hrs
100% - 8 hrs

Lithium Battery Package
80% - 4 hrs
100% - 6 hrs

General

Curb Weight

Lead-Acid Battery Package
1036 lb (470 kg) *

Lithium Battery Package
886 lb (402 kg) *

Passenger Capacity

1+1 Passenger
1+3 Passenger

Capacity

Load : 881 lb (400 kg)

Tow: 1102 lb (500 kg)

Tyre Dimensions

18 x 8.5-8 (6 PLY)
20.5 x 8-10 (6 PLY)
22 x 9.50-10 Off-Road Tyre **
